Standard Colour: Black, Red, Blue, Yellow and Green (For Earthing)

Material: PVC

Brand: Vasavi

Nominal area of copper Conductor: 1.0, 1.5, 2.5, 6.0, 10.0, 16.0, 25.0, 35.0 Sq.mm

Number/Nominal Diameter of strands: 14/.3*, 22/.3*, 36/.3*, 84/.3**, 140/0.3**,126/0.4**, 196/0.4**, 276/0.4**mm

Thickness of insulation (Nominal): 0.8, 1.0, 1.20mm

Approximate Overall Diameter of wire: 2.8, 3.1,3.8, 5.0, 7.0, 8.2, 9.7, 10.9 mm

Resistance (Max.) per Km. @20°C: 18.10, 12.10, 7.41, 3.30, 1.91, 1.21, 0.78, 0.554 Ohms

Country of Origin: Made in India

Indoor/Outdoor: Indoor, Outdoor

Project Type: Commercial, Residential

Current carrying capacity 2 wires, single phase

In conduit/ Trunking: 11, 13, 18, 31, 57, 71, 91 Amps

Unenclosed-clipped directly to a surface or on cable tray Amps: 12, 16, 22, 37, 68, 86, 110 Amps

• Supplied in 90 meter lengths in attractive carton

• BIS License No. CM/L-6054760

• *As per conductor Class 2 of IS 8130 : 1984

• **As per conductor Class 5 of IS 8130 : 1984

Type: Cable Wires
